Z3R6522X 1080P Auto Focus IR Vandal Resistant Dome IP Camera

Z3R6522X 1080P Day & Night Auto Focus IR Vandal Resistant Dome IP Camera from Alfa Iris delivers high-performance surveillance with advanced imaging, intelligent analytics, and rugged durability. Featuring a 2MP CMOS sensor with Full HD 1080P resolution, this camera ensures clear, detailed video in both day and night conditions. Equipped with motorized zoom and auto focus, it allows flexible installation and precise image adjustment for a wide range of security applications.

Advanced Imaging and Night Surveillance

The Z3R6522X utilizes H.265/H.264 compression for efficient bandwidth and storage management while maintaining superior image quality. With HDR up to 120dB, 3D noise reduction, and 2D WDR, it performs exceptionally well in challenging lighting environments. Its built-in IR LEDs provide illumination up to 30 meters, ensuring reliable night vision even in complete darkness.

• Full HD 1080P (2MP) resolution
• H.265/HEVC and H.264/AVC dual streaming
• Motorized lens (2.8–8mm) with auto focus
• HDR up to 120dB for high contrast scenes
• IR night vision up to 30 meters

Smart Detection and Intelligent Video Analytics

This dome camera supports IVS (Intelligent Video Surveillance) features, including motion detection, tripwire detection, object counting, and optional advanced analytics such as face detection, loitering detection, and crowd monitoring. It also includes tampering and network loss detection, ensuring proactive security monitoring for critical environments.

• Motion, tampering, and network loss detection
• Tripwire and object counting analytics
• Optional advanced AI features (face, crowd, loitering detection)
• Smart event notifications via FTP, SMTP, HTTP, and push alerts

Rugged Design for Harsh Environments

Built with a मजबूत IK10 vandal-resistant aluminum housing and IP67-rated weatherproof protection, the Z3R6522X is designed for reliable operation in extreme conditions. It performs in temperatures ranging from -40°C to +50°C, making it ideal for both indoor and outdoor installations.

• IK10-rated vandal-resistant casing
• IP67 waterproof and dustproof design
• Operating temperature: -40°C to +50°C
• Suitable for wall, ceiling, and pole mounting

Flexible Integration and Network Compatibility

With support for ONVIF Profile S and T, the camera integrates بسهولة with third-party VMS platforms and network systems. It supports PoE (IEEE 802.3af) for simplified installation and offers multiple streaming options, user access control, and secure encryption protocols for safe remote monitoring.

• ONVIF Profile S & T compatibility
• PoE and DC12V power options
• Up to 4 simultaneous video streams
• Secure access with HTTPS, 802.1x, and IP filtering

Security professionals seeking a reliable, high-performance dome IP camera will find the Z3R6522X from Alfa Iris an excellent choice for commercial buildings, industrial facilities, and outdoor surveillance applications. :contentReference[oaicite:0]{index=0}

Technical Specifications

• Model: Z3R6522X
• Image Sensor: 1/2.8" CMOS, 2MP
• Resolution: 1920 × 1080 @ 30fps
• Lens: 2.8 – 8 mm motorized (auto focus)
• Min. Illumination: 0.02 Lux (Color), 0 Lux with IR
• IR Distance: Up to 30 meters
• Compression: H.265 / H.264 / MJPEG
• WDR: 2D WDR, HDR up to 120dB
• Audio/Video Streaming: RTP/HTTP, RTP/TCP, RTP/UDP, Multicast
• Network: 10/100 Mbps Ethernet, IPv4/IPv6
• Power: DC12V / PoE (IEEE 802.3af)
• Power Consumption: 6.3W (DC), 8.1W (PoE)
• Operating Temperature: -40°C to +50°C
• Protection: IP67, IK10
• Dimensions: Ø115 × 91 mm
• Weight: 435g
