AC-215IP-PCBA Scalable Networked Access Control Panel PCB for Two Readers
Advanced networked access control solution designed for scalable security management across multiple facilities. Supports two reader connections with flexible door configurations for commercial and industrial environments. Features TCP IP communication, large user capacity, and offline operation capability for reliable access management. Compatible with professional security software platforms and supports extensive event history storage. Alfa Iris LLC is a trusted provider of professional CCTV surveillance and smart security systems, delivering advanced solutions for industrial, commercial, and high-security environments.
- Supports up to 30000 user credentials
- Two reader ports with flexible door configuration
- TCP IP onboard communication interface
- Stores up to 20000 event records
- Expandable network supports 2046 doors
Supports scalable networked access control with connectivity for up to 1023 panels and 2046 doors across multiple remote locations.
Designed with dual reader ports, supporting flexible 1-door or 2-door configurations including In/Out, In/In, and Out/Out setups.
Provides advanced TCP/IP communication through an onboard RJ-45 Ethernet connection for reliable network integration.
Manages up to 30,000 active users and credentials, making it ideal for medium to large commercial access control systems.
Stores up to 20,000 event records, enabling detailed access monitoring and audit trail reporting.
Supports both online and offline operation to maintain access functionality during network interruptions.
Features four supervised high-impedance inputs for enhanced system monitoring and device integration.
Includes four fully programmable relay outputs rated at 5A @ 30VDC for controlling locks, alarms, and automation devices.
Compatible with Rosslare’s AxTraxNG™ Server software for centralized access management and automation capabilities.
Offers multiple communication speed options including 9600, 19200, 57600, and 115200 bps for flexible system configuration.
Operates on 12VDC power with low standby current consumption, ensuring efficient and reliable performance.
Built as a Printed Circuit Board Assembly (PCBA) for streamlined installation into custom enclosures and access systems.
Supports LED control outputs, tamper input functionality, and D0/D1 reader communication for enhanced security integration.
Certified to CE and FCC standards, ensuring compliance with international safety, EMC, and radio interference regulations.
Ideal for commercial buildings, industrial facilities, multi-site enterprises, and professional-grade access control deployments.
| MODEL NAME | Rosslare AC215IP Scalable Networked Access Control PCBA |
| PRODUCT TYPE | Networked Access Control Panel PCBA |
| MANUFACTURER | Rosslare |
| MODEL NUMBER | AC215IP |
| SKU | ROS-AC-215IP-PCBA |
| NSID | 25217 |
| SYSTEM TYPE | Scalable Networked Access Control System |
| BOARD TYPE | Printed Circuit Board Assembly Only |
| READER SUPPORT | 2 Reader Ports |
| DOOR SUPPORT | Supports 1 or 2 Doors |
| DOOR CONFIGURATIONS | In/Out, In/In, Out/Out |
| NETWORK CAPACITY | Up to 1023 Panels |
| MAXIMUM DOORS | Up to 2046 Doors |
| USER CAPACITY | 30,000 Active Credentials |
| ACCESS TYPES | Card and PIN |
| EVENT HISTORY | 20,000 Event Log Capacity |
| COMMUNICATION INTERFACE | TCP/IP |
| ETHERNET PORT | 10/100 Ethernet Port |
| RJ-45 CONNECTION | Onboard RJ-45 Connector |
| SUPPORTED SPEEDS | 9600, 19200, 57600, 115200 bps |
| SERVER SOFTWARE | Rosslare AxTraxNG™ Server |
| OPERATING SYSTEM SUPPORT | Microsoft Windows |
| ONLINE OPERATION | Supported |
| OFFLINE OPERATION | Supported |
| INPUTS | 4 Supervised High-Impedance Inputs |
| MAX INPUT VOLTAGE | 5 VDC |
| OUTPUTS | 4 Fully Programmable Relay Outputs |
| RELAY TYPE | N.O. and N.C. Relays |
| RELAY RATING | 5A @ 30VDC |
| OUTPUT VOLTAGE | 12 VDC |
| MAX OUTPUT CURRENT | 300 mA |
| OPERATING VOLTAGE | 12 VDC 1.5A from PS-14 |
| STANDBY CURRENT | 120 mA |
| MAXIMUM CURRENT | 370 mA |
| LED CONTROL | D0/D1 LED Control Output |
| TAMPER INPUT | Supported |
| NETWORK SCALABILITY | Expandable Multi-Site Architecture |
| INSTALLATION TYPE | Professional Access Control Installation |
| APPLICATION | Commercial Access Control Systems |
| REMOTE PREMISE SUPPORT | Multiple Remote Premises Supported |
| SECURITY LEVEL | High Security Professional Performance |
| NETWORKING MODE | LAN-Based Access Control |
| ACCESS MANAGEMENT | Centralized User Administration |
| CREDENTIAL STORAGE | Internal Memory Storage |
| EVENT STORAGE | Internal Event Buffer |
| COMMUNICATION PROTOCOL | Ethernet TCP/IP Protocol |
| SYSTEM EXPANSION | Scalable Panel Networking |
| READER COMPATIBILITY | Supports Dual Reader Operation |
| ENCLOSURE | PCBA Only Without Housing |
| MOUNTING REQUIREMENT | Requires Compatible Enclosure |
| OPERATING ENVIRONMENT | Indoor Installation Recommended |
| SYSTEM MANAGEMENT | AxTraxNG™ Management Software |
| FIRMWARE SUPPORT | Rosslare Access Control Firmware |
| DOOR CONTROL | Networked Door Access Management |
| ALARM INTEGRATION | Programmable Relay Integration |
| USER AUTHENTICATION | Card and PIN Authentication |
| SYSTEM MONITORING | Real-Time Event Monitoring |
| PROGRAMMABLE FUNCTIONS | Fully Programmable Outputs |
| POWER REQUIREMENTS | External 12VDC Power Supply Required |
| ACCESS CONTROL TYPE | Enterprise Access Control |
| CONTROL PANEL TYPE | IP-Based Access Controller |
| NETWORK TOPOLOGY | Distributed Network Architecture |
| INSTALLATION APPLICATION | Commercial and Industrial Facilities |
| CERTIFICATIONS | CE, ENC, RFI, LVD RED 2014/53/EU |
| FCC COMPLIANCE | CFR47 Part 15b |
| WARRANTY | 2-Year Limited Warranty |
| SYSTEM INTEGRATION | Supports Enterprise Security Integration |
| REMOTE MANAGEMENT | Network-Based Remote Administration |
| EVENT TRACKING | Detailed Access Event Logging |
| ACCESS LEVELS | User-Based Access Rights Management |
| SOFTWARE PLATFORM | Windows-Based Management Platform |
| PANEL COMMUNICATION | Ethernet Network Communication |
| PROFESSIONAL GRADE | Commercial Security Hardware |
| INSTALLATION FLEXIBILITY | Supports Various Door Configurations |
| POWER CONNECTION | 12VDC Input Connection |
| INPUT MONITORING | Supervised Input Monitoring |
| OUTPUT CONTROL | Programmable Relay Switching |
| DATA COMMUNICATION | High-Speed Serial Communication |
| SYSTEM ARCHITECTURE | Scalable IP-Based Access System |
| SECURITY MANAGEMENT | Centralized Security Administration |
| ACCESS EVENT CAPACITY | 20,000 Stored Transactions |
| USER DATABASE | 30,000 User Database Capacity |
| NETWORK EXPANSION | Supports Large Scale Deployments |
| PANEL FUNCTION | Door Access Monitoring and Control |
| RELAY PROGRAMMING | Customizable Relay Logic |
| SECURITY APPLICATION | Professional Building Access Control |
| SYSTEM RELIABILITY | Designed for Continuous Operation |
| ACCESS CONTROL NETWORK | Enterprise Ethernet Network |
| HARDWARE CONFIGURATION | PCB Assembly Configuration |
| PRODUCT CATEGORY | Access Control Hardware |
Rosslare AC215IP Networked Access Control Panel is a scalable and secure 2-reader access control solution designed for professional commercial and industrial security applications. Engineered for high-performance deployments, this TCP/IP-enabled control panel supports both online and offline operation while seamlessly integrating with Rosslare AxTraxNG™ Server software for centralized management and automation.
Advanced Networked Access Control Performance
The AC215IP provides flexible configuration options for one-door and two-door setups, making it ideal for office buildings, gated facilities, warehouses, apartment complexes, and enterprise security systems. Supporting up to 30,000 users and storing up to 20,000 event logs, this controller delivers dependable access management for medium to large-scale installations.
- Supports up to 2 readers and 2 doors
- Network scalable up to 1023 panels and 2046 doors
- Stores up to 30,000 user credentials
- 20,000 event history log capacity
- TCP/IP communication with onboard RJ-45 Ethernet port
Flexible Integration and Reliable Operation
Designed for installers and security integrators, the Rosslare AC215IP features programmable relay outputs, supervised inputs, and multiple communication speed options for reliable integration into existing security infrastructures. Its compact Printed Circuit Board Assembly (PCBA) format allows flexible enclosure customization and streamlined installation.
- Supports 1-door and 2-door configurations
- 4 supervised high-impedance inputs
- 4 programmable relay outputs rated at 5A @ 30VDC
- Compatible with Rosslare AxTraxNG™ management software
- Supports online and offline operation modes
Built for Commercial Security Applications
Operating on 12VDC, the AC215IP controller is designed for long-term reliability in demanding commercial environments. Security professionals can deploy this solution across corporate facilities, industrial properties, educational campuses, healthcare buildings, and multi-site access control systems requiring centralized monitoring and scalable infrastructure.
- Commercial office access control systems
- Industrial and warehouse security applications
- Apartment and gated community entry management
- Educational and healthcare facility access control
The Rosslare AC215IP delivers enterprise-grade access control scalability, secure TCP/IP networking, and dependable performance for professional security installations requiring advanced credential management and centralized control.
Technical Specifications
- Model: AC215IP
- Type: Printed Circuit Board Assembly (PCBA)
- Reader Support: 2 reader ports
- Door Configurations: 1-door or 2-door operation
- Users Capacity: 30,000 credentials
- Event Log Capacity: 20,000 events
- Communication Interface: TCP/IP
- Ethernet Port: 10/100 RJ-45 onboard connector
- Inputs: 4 supervised high-impedance inputs
- Outputs: 4 programmable relay outputs (5A @ 30VDC)
- Operating Voltage: 12VDC
- Maximum Input Current: 370mA
- Networking Software: Rosslare AxTraxNG™ Server
- Compliance: CE, FCC, LVD RED 2014/53/EU
- Warranty: 2-Year Limited Warranty
